82ZYT Brush DC Motor
82ZYT Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
82ZYT122220 | 220 | ≤0. 1 | 1400±8% | ≤0.4 | 1000±8% | 0.4 | 42 | 122 |
82ZYT157220 | 220 | ≤0. 1 | 1500±8% | ≤0.7 | 1200±8% | 0.7 | 88 | 157 |
B82ZYT1011229 | 12 | ≤1.72 | 2900±8% | ≤6. 57 | 2300±8% | 0.2 | 48 | 101 |
B82ZYT1011232 | 12 | ≤1.7 | 3200±8% | ≤7.2 | 2500±8% | 0.2 | 52 | 101 |
B82ZYT10112A | 12 | ≤1.9 | 3800±8% | ≤8. 5 | 3000±8% | 0.2 | 63 | 101 |
B82ZYT10112B | 12 | ≤1.7 | 3800±8% | ≤9. 5 | 3000±8% | 0.2 | 67 | 101 |
C82ZYT9424 | 24 | ≤1 | 2800±8% | ≤7 | 2500±8% | 0.4 | 105 | 94 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
