83ZYT Brush DC Motor
83ZYT Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
A83ZYT135220 | 220 | 0. 16 | 5600±8% | 1.60 | 5000±8% | 0. 5 | 262 | 135 |
A83ZYT135110 | 110 | 0.32 | 5600±8% | 3.00 | 5000±8% | 0. 5 | 262 | 135 |
A83ZYT135220 | 220 | 0. 18 | 6000±8% | 2.00 | 5500±8% | 0. 5 | 288 | 135 |
A83ZYT166220A | 220 | 0. 18 | 5100±8% | 2. 50 | 4500±8% | 0.8 | 377 | 166 |
A83ZYT166220B | 220 | 0. 18 | 7000±8% | 3. 50 | 6300±8% | 0.8 | 528 | 166 |
B83ZYT145220 | 220 | 0. 16 | 5600±8% | 1.60 | 5000±8% | 0. 5 | 262 | 145 |
B83ZYT145110 | 110 | 0.32 | 5600±8% | 3.00 | 5000±8% | 0. 5 | 262 | 145 |
B83ZYT176220 | 220 | 0. 18 | 5100±8% | 2. 50 | 4500±8% | 0.8 | 377 | 176 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
