FPC

1

Vcc

Hall power source input +5VDC～+24VDC

2

Hall W

3

Hall U

4

Hall V

5

GND

Hall ground

6

Phase W

7

Phase V

8

Phase U

FL32BLW18-9V-3706A

8

3

9

3700

2100

29.5

6

73.8

3.4

2.87

1.61

FL32BLW18-

12V-4607A

8

3

12

4600

2800

25.1

7

75.3

3.2

3.43

1.87

FL32BLW18-24V-4507A

8

3

24

4500

2760

25.5

7

76.5

1.7

13.7

7.73

FL32BLW18-48V-4808A

8

3

48

4800

2950

24.7

8

74.1

0.97

53

27.8

9V

Rated speed    r/min

566

405

150

111

78

60

43

36

31

26

22

18

12

9.6

8.3

Rated torque    N.m

0.099

0.14

0.33

0.45

0.65

0.84

1.1

1.3

1.5

1.8

2.0

2.5

3.5

4.2

4.9

12V

Rated speed  r/min

755

541

200

147

104

80

57

47

41

34

29

24

15

13

11

Rated torque    N.m

0.084

0.12

0.28

0.39

0.55

0.71

0.90

1.1

1.2

1.5

1.7

2.1

3.0

3.6

4.1

24V

Rated speed  r/min

744

533

197

145

102

79

56

47

41

34

29

24

15

13

11

Rated torgue N.m

0.085

0.12

0.29

0.39

0.56

0.72

0.91

1.1

1.3

1.5

1.8

2.1

3.0

3.6

4.2

48V

Rated speed  r/min

795

569

211

155

109

84

60

50

43

36

31

26

16

14

12

Rated torque    N.m

0.082

0.12

0.28

0.38

0.54

0.70

0.88

1.1

1.2

1.5

1.7

2.1

2.9

3.5

4.1

Number of gear trains

1

1

2

2

2

2

3

3

3

3

3

3

4

4

4

Length(L)              mm

25.7

25.7

32.8

32.8

32.8

32.8

39.7

39.7

39.7

39.7

39.7

39.7

46.6

46.6

46.6

N.m Max. permissible load in a short time

1.5

1.5

6

6

6

6

10

10

10

10

10

10

12

12

12
