55ZYN Brush DC Motor
55ZYN Brush DC Motor
Model | Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
55ZYN7430A | 30 | ≤0.3 | 1800±8% | ≤1.2 | 1400±8% | 0. 12 | 18 | 74 |
55ZYN7430B | 30 | ≤0.3 | 1800±8% | ≤1.2 | 1400±8% | 0. 12 | 18 | 74 |
55ZYN7424 | 24 | ≤0.4 | 3600±8% | ≤2.7 | 3000±8% | 0. 12 | 38 | 74 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
