57ZYN Brush DC Motor
57ZYN Brush DC Motor
Model | Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
57ZYN10136 | 36 | ≤0.25 | 2500±8% | ≤2.9 | 2000±8% | 0.3 | 63 | 101 |
57ZYN9124 | 24 | ≤0.32 | 2600±8% | ≤3. 1 | 2200±8% | 0.2 | 46 | 91 |
57ZYN8624 | 24 | ≤0.36 | 3000±8% | ≤2.6 | 2500±8% | 0. 15 | 39 | 86 |
57ZYN8124A | 24 | ≤0.4 | 3600±8% | ≤2.6 | 3000±8% | 0. 12 | 38 | 81 |
57ZYT10124 | 24 | ≤0.35 | 2800±8% | ≤3 | 2200±8% | 0.2 | 46 | 101 |
57ZYT9112 | 12 | ≤0.4 | 2400±8% | ≤3.6 | 1800±8% | 0. 13 | 25 | 91 |
57ZYT8624 | 24 | ≤0.38 | 3100±8% | ≤1.8 | 2500±8% | 0. 1 | 26 | 86 |
57ZYT8124B | 24 | ≤0. 5 | 3600±8% | ≤1.9 | 3000±8% | 0.08 | 25 | 81 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
