Max. Radial load（10mm from flange）

50N

40N

Max. shaft axial load

30N

30N

Radial play of shaft（ near to flange）

≤0.08 mm

≤0. 1mm

Axial play of shaft

≤0.3 mm

≤0.3 mm

Single Shaft

A

Ω

mH

N.m

N.m

#

g-cm2

kg

mm

FL28STH32-0674A

0.67

5.6

3.4

0.060

0.005

4

9

0.11

32 max

FL28STH32-0956A

0.95

2.8

1.0

0.043

0.005

6

9

0.11

32 max

Number of gear trains

1

2

3

Length(L2)         mm

22.6

29.2

35.6

Max. rated torque

N.m

0.4

1.0

2.0

Short time permissible torque

N.m

1.2

3.0

6.0

Efficiency                         %

90%

81%

73%

Backlash at no-load

0.5°

1.0°

1.5°

Weight                              g

68

93

120
