88ZYT Brush DC Motor
88ZYT Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
88ZYT9423 | 23 | ≤0.6 | 2800±8% | ≤4.3 | 2200±8% | 0.25 | 58 | 94 |
88ZYT13512A | 12 | ≤1.3 | 2300±8% | ≤13 | 1700±8% | 0. 5 | 89 | 135 |
88ZYT13512B | 12 | ≤1.4 | 2300±8% | ≤12 | 1800±8% | 0. 5 | 94 | 135 |
88ZYT15524 | 24 | ≤2 | 3600±8% | ≤18 | 3000±8% | 1 | 314 | 155 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
