88ZYN Brush DC Motor
88ZYN Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
88ZYN10820 | 20 | ≤3. 5 | 3800±8% | ≤18 | 3300±8% | 0.75 | 259 | 108 |
88ZYN10824 | 24 | ≤3. 5 | 3600±8% | ≤20 | 3000±8% | 1 | 314 | 108 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
