106ZYT Brush DC Motor
106ZYT Brush DC Motor
| Voltage V | Noload | Rated load | Torque Nm | Power W | Length mm | ||
Current A | Speed rpm | Current A | Speed rpm | |||||
106ZYT200220A | 220 | ≤0. 5 | 5500±8% | ≤5 | 5000±8% | 1. 5 | 785 | 200 |
106ZYT200220B | 220 | ≤0.4 | 4500±8% | ≤4. 1 | 4000±8% | 1. 5 | 628 | 200 |
Note: the above is only representative products,
specific shape and performance parameters can be customized according to customer requirements.
